Manual 37365A GCP-30 Series Packages - Genset Control
© Woodward Page 151/179
No. Output Explanation
81 CCW mains rotating field
82 Engine enable
Set engine enable
As long as there is a start request for
the engine and during cool down, the
operation of the engine is enabled
(i.e. AUTOMATIC operation mode
and discrete input 3/5, emergency
power, start via interface, manual
start, etc. are energized/enabled).
Reset engine enable
The engine enable will be reset if a
start request is no longer present due
to a manual stop, an F3 alarm class,
or during the engine stop time, and if
"zero" speed is detected and a start
request is not present or coasting is
not taking place.
83 "RESET" button pressed
84 Preheating/firing ON (pre-assigned to relay [7]) pre-assigned default value
85 Group alarm of class F1, F2, or F3 alarm (pre-assigned to relay [8]) pre-assigned default value
Horn: after 2 min independent shu-
toff
86
#1
--Internal--
87
#1
--Internal--
88 Generator voltage and/or frequency are not in range (undelayed)
89 Busbar voltage and/or frequency are not in range (undelayed)
90
#1
--Internal--
91 MPU detects nominal speed (+/-6 %)
92 Mains voltage fault via protection device
93 Mains frequency fault via protection device
94 Phase/vector shift fault via protection device
95
#1
--Internal--
96 Delayed engine monitoring time exceeded
97 Sprinkler mode is active (included Sprinkler coasting)
98
#2
IKD1 discrete input 1
99
#2
IKD1 discrete input 2
100
#2
IKD1 discrete input 3
101
#2
IKD1 discrete input 4
102
#2
IKD1 discrete input 5
103
#2
IKD1 discrete input 6
104
#2
IKD1 discrete input 7
105
#2
IKD1 discrete input 8
106
#2
IKD2 discrete input 1
107
#2
IKD2 discrete input 2
108
#2
IKD2 discrete input 3
109
#2
IKD2 discrete input 4
110
#2
IKD2 discrete input 5
111
#2
IKD2 discrete input 6
112
#2
IKD2 discrete input 7
113
#2
IKD2 discrete input 8
#1
special versions only
#2
(Option SC10)
