No. Output Explanation
114
#1
Three-position controller: n+ / f+ / P+
(use an external Resistive/Capacitive
protection circuit)
115
#1
Three-position controller: n- / f- / P-
116
#1
Three-position controller: V+ / Q+
117
#1
Three-position controller: V- / Q-
118
#2
--Internal--
119
#3
Wire break Analog input [T1]
120
#3
Wire break Analog input [T2]
121
#3
Wire break Analog input [T3]
122
#3
Wire break Analog input [T4]
123
#3
Wire break Analog input [T5]
124
#3
Wire break Analog input [T6]
125
#3
Wire break Analog input [T7]
126
#2
--Internal--
127
#2
--Internal--
128
#2
--Internal--
129
#4
Failure lambda probe
130
#4
Lambda controller ON
131 Fuel relay is ON / stop relay is ON / gas valve is ON
132
#2
--Internal--
133 Idle mode active
134
#4
IKD1 communication OK
135
#4
IKD2 communication OK
136
#4
ST3 communication OK
137
#4
MDEC communication OK
138
#4
J1939 communication OK
139 Phase rotation generator and mains mismatch
140 Direction of rotation, mains voltage: CW
141 Direction of rotation, generator voltage: CCW
142 Direction of rotation, generator voltage: CW
143 Starter engaged (cranking)
144 GCB is to be opened
145
#2
--Internal--
146 Parallel operation CB from V4.3010
147
#2
--Internal--
148 Unintended stop from V4.3010
149 Interface error X1/X5 from V4.3010
150
#4
ECU yellow alarm from V4.3030
151
#4
ECU red alarm from V4.3030
152
#2
--Internal--
153
#2
--Internal--
154
#2
--Internal--
155
#2
--Internal--
156
#2
--Internal--
157 Engine cool down from V4.3046
158 Mains settling time is running from V4.3046
#1
(BPQ, XPQ Package)
#2
special versions only
#3
(XPD, XPQ Package)
#4
(Option SC10)
NOTE
Relay Manager functions with a number above 128 may only be configured with LeoPC1 Version
3.0.015 or later.
