RJ-901C/RJ-900C Maintenance Manual 4 Parts Replacement
4-69
2. Take the CR tape wires off the clamps nearby the main board, then pull them out through the R frame
cable inlet.
3. Take the CR tape wire off the clamp (one point) nearby the R frame cable inlet (I/H assembly side).
No. Part name
1 CR tape wire
2 Clamp
No. Part name
1 CR tape wire
2 Clamp
1
2
1
2
