Xerox 7142 Service Manual

4 Parts Replacement RJ-901C/RJ-900C Maintenance Manual
4-70
4. Remove the bearer holder-retaining screw (pan-head screw with spring washer and flat washer M3 × 6:
2pcs), then remove the bearer holder.
5. Remove the tube holder 1 and the tube holder 2.
No. Part name
1 Tube holder 2
2 Bearer holder and bearer
holder screw
No. Part name
1 Tube holder 1
2 Tube holder 2
1
2
1
2
