RJ-901C/RJ-900C Maintenance Manual 5 Self-Diagnosis Mode
5-65
5.9.4 Head Lock Endurance Menu
This menu performs endurance running for the head lock.
In this endurance menu, the head lock operation can be performed according to the value set.
CAUTION
When the head lock endurance running is performed, note the following;
• Install available ink cartridges.
If the head lock endurance running is performed without ink cartridges, ink inside the tube
may leak through the ink holder during the carriage movement.
TIP
• If the number of endurance running cycles is set to -1, the carriage continuously repeat endurance
running until cancel input is given from the operation panel.
• The maximum counter value for endurance running cycles is 99999999 (up to 8-digit number). If
the number of cycles exceeds the maximum value, the counter is reset to 0.
• The waiting time is not modifiable.
Table 5-19 Set Items in Head Lock Endurance Menu
Set item Contents Set value Remark
Waiting interval Set the waiting interval per
endurance running cycle
completion.
10 Unit: sec.
Number of endurance
running cycles
Set the number of endurance
running cycles
-1 to 10000
Endurance count
Check waiting time
Performing endurance
[Enter] key
[Enter] key
[Enter] or [Cancel] key
To Next Page
