7 Adjustment RJ-901C/RJ-900C Maintenance Manual
7-2
7.10 PG Height Adjustment ..........................................................................7- 31
7.10.1 Jigs and Tools .............................................................................. 7-31
7.10.2 Adjustment Procedure.................................................................. 7-31
7.11 Media Sensor Sensitivity Adjustment .................................................7- 32
7.11.1 P_EDGE Sensor Sensitivity Adjustment ...................................... 7-33
7.11.2 P_REAR Sensor Adjustment........................................................ 7-35
