RJ-901C/RJ-900C   Maintenance Manual 7 Adjustment
7-5
Main board
assembly
1 Parameter backup "5.5.2 Head Rank
Input Menu" p.5-25
2 Firmware installation "5.5.3 Head Nozzle
Check Menu" p.5-26
3 Voltage input (no need for initial ink
charge)
"5.5.2 Head Rank
Input Menu" p.5-25
4 Head nozzle check "5.5.3 Head Nozzle
Check Menu" p.5-26
5 Repeatability adjustment "5.5.7
Repeatability
Adjustment Menu"
p.5-35
6 Band feed correction "5.5.9 Band Feed
Correction Menu"
p.5-41
7 Top & bottom adjustment "5.5.10 Top and
Bottom Adjustment
Menu" p.5-42
8 P_REAR sensor position adjustment "5.5.11 P_REAR
Sensor Position
Adjustment Menu"
p.5-43
9
Media sensor sensitivity adjustment
"7.11 Media
Sensor Sensitivity
Adjustment" p.7-33
10 Test printing "5.5.12 Test
Printing Menu" p.5-44
CR motor assembly 1 CR belt tension adjustment "7.6 CR Belt
Tension Adjustment"
p.7-25
2 Repeatability adjustment "5.5.7
Repeatability
Adjustment Menu"
p.5-35
3 Top & bottom adjustment "5.5.10 Top and
Bottom Adjustment
Menu" p.5-42
4 Test printing "5.5.12 Test
Printing Menu" p.5-44
Table 7-1 Adjustment Item List(Continued)
Part replaced or
adjusted
Adjustment
order
Adjustment item Reference
