7 Adjustment RJ-901C/RJ-900C Maintenance Manual
7-6
PF motor assembly 1 PF speed reduction belt tension
adjustment
"(2) Confirming
Completion of
Installation to Plotter"
p.7-17
2 Band feed correction "5.5.9 Band Feed
Correction Menu"
p.5-41
3 Top & bottom adjustment "5.5.10 Top and
Bottom Adjustment
Menu" p.5-42
4 P_REAR sensor position adjustment "5.5.11 P_REAR
Sensor Position
Adjustment Menu"
p.5-43
5 Test printing "5.5.12 Test
Printing Menu" p.5-44
P_EDGE sensor
assembly
1
Media sensor sensitivity adjustment
"7.11 Media
Sensor Sensitivity
Adjustment" p.7-33
2 Top / bottom adjustment "5.5.10 Top and
Bottom Adjustment
Menu" p.5-42
P_REAR sensor
assembly
1
Media sensor sensitivity adjustment
"7.11 Media
Sensor Sensitivity
Adjustment" p.7-33
2 P_REAR sensor position adjustment "5.5.11 P_REAR
Sensor Position
Adjustment Menu"
p.5-43
Cover sensor
assembly
1 Cover sensor assembly mounting
position adjustment
"7.7 Head
Alignment
Adjustment(Horizont
al Height)" p.7-26
Table 7-1 Adjustment Item List(Continued)
Part replaced or
adjusted
Adjustment
order
Adjustment item Reference
