Xerox 7142 Service Manual

7 Adjustment RJ-901C/RJ-900C Maintenance Manual
7-8
Cutter holder
assembly
1 Cutter holder assembly mounting
position adjustment
"7.8 Head
Alignment
Adjustment(Slant)"
p.7-28
2 P_EDGE sensor adjustment "7.11.1 P_EDGE
Sensor Sensitivity
Adjustment" p.7-34
3 Print margin adjustment "5.5.10 Top and
Bottom Adjustment
Menu" p.5-42
4 Cutter endurance operation check "5.9.3 Cutter
Endurance Menu"
p.5-64
Carriage assembly 1 CR belt tension adjustment "7.6 CR Belt
Tension Adjustment"
p.7-25
2 CR encoder inspection "5.4.5 Encoder
Menu" p.5-16
3 Cutter holder assembly mounting
position adjustment
"7.8 Head
Alignment
Adjustment(Slant)"
p.7-28
4 P_EDGE sensor adjustment "7.11.1 P_EDGE
Sensor Sensitivity
Adjustment" p.7-34
5 Cutter endurance operation check "5.9.3 Cutter
Endurance Menu"
p.5-64
6 Sequential printing endurance operation
check
"5.9.6 Print Head
Endurance (Nozzle
Print) Menu" p.5-67
7
Head rank input
"5.5.2 Head Rank
Input Menu" p.5-25
"5.9.6 Print Head
Endurance (Nozzle
Print) Menu" p.5-67
Table 7-1 Adjustment Item List(Continued)
Part replaced or
adjusted
Adjustment
order
Adjustment item Reference
