RJ-901C/RJ-900C Maintenance Manual 9 Troubleshooting
9-55
8
9
10
11
11. Does pump motor
rotate during cleaning
operation?
• Reconnect main board
assembly connector
J102, J103.
• Replace pump motor
assembly.
• Replace main board
assembly.
"4.3.3
Replacing
Main Board
Assembly"
p.4-21
"4.7.1
Removing
Maintenance
Base
Assembly"
p.4-47
"4.3.3
Replacing
Main Board
Assembly"
p.4-21
12. When cleaning
operation is
performed, does
transmission gear
rotate properly?
Replace maintenance base
assembly.
"4.7.1
Removing
Maintenance
Base
Assembly"
p.4-47
13. When cleaning
operation is
performed, are gears
and transmission gear
shaft damaged?
Replace maintenance base
assembly.
"4.7.1
Removing
Maintenance
Base
Assembly"
p.4-47
14. Is spring of ink system
assembly detached or
damaged?
• If the part is detached,
remount it.
• If the part is damaged,
replace ink system
assembly.
"4.7.2
Replacing
Pump Cap
Assembly"
p.4-52
15. Is ink tube in ink
system assembly bent?
• Replace ink system
assembly and check if
cleaning operation
causes ink inflow.
• If ink inflow is
confirmed, execute
initial ink charge.
"4.7.2
Replacing
Pump Cap
Assembly"
p.4-52
16. Is registered head
voltage different from
actual head voltage?
Enter correct head voltage. "5.5.2
Head Rank
Input Menu"
p.5-25
Table 9-11 Symptoms, Check Items and Actions for Printing Problems(Continued)
No. Symptom Check item Action Reference
