RJ-901C/RJ-900C 　 Maintenance Manual 2 Product Overview
2-7
(1) Operation Keys
NOTE
Some keys have multiple functions and names depending on the plotter status (normal or setup menu
display). See "2.4 Plotter Status" p.2-9 for more details.
No. Name Normal Setup menu display
1
[Menu] key
Changes the LCD monitor display to
setup menu status.
Changes the setup menu display
status to normal status.
2 [Enter] key Stops the buzzer at "Little ink" and
"No ink" errors.
- Selects the menu to be set and shifts
to the next hierarchy.
- Determines and saves the parameter
value.
[Cleaning] key If held down for 2 seconds or more,
starts cleaning the plotter head.
-
3 [Cancel] key - During plotting: Terminates printing
forcibly and deletes 1 file of
remaining data.
- During reception/analysis: Deletes
the data that has been already
received/analyzed and ignores 1 file
of data received after that.
- During ink drying time wait status:
Releases the ink drying time wait
status and ejects the media.
- Returns to the previous menu
hierarchy. Changed parameter values
are disabled.
- Changes the setup menu display
status to normal status.
[Cut] key If roll media is set, cuts the media at
the present position.
-
4 [Back] key Sets the media type.
- The lamp for the type that is set
lights on (green).
Changes the menu in reverse order.
5 [Next] key Sets the plot mode and color mode.
- The lamp for the plot mode and
color mode that is set lights on
(green).
Changes the menu in forward order.
6 [Backward feed] key Feeds the media in the reverse
direction.
-
[Setting/value +] key - - Changes the setting value in the
forward direction.
- Increases the value when inputting
values.
To Next Page
