2 Product Overview RJ-901C/RJ-900C　 Maintenance Manual
2-8
(2) LCD Monitor and Status Lamps
7 [Forward feed] key Feeds the media in the forward
direction.
-
[Setting/value -] key - - Changes the setting value in the
reverse direction.
- Decreases the value when inputting
values.
8 [Power] key Turns the plotter on and off. Turns the plotter on and off.
No. Name Color Status Function
9 Power lamp Green On The plotter is switched on.
Blinking An error has occurred. The contents will be displayed on the
LCD monitor.
Off The plotter is switched off.
10 Data lamp Red On - The plotter is analyzing received data.
- The plotter is printing data.
Blinking The plotter is receiving data.
Off The plotter is not receiving, analyzing or printing data.
11 Roll lamp Green On The media loaded in the plotter is set to roll media.
Off The media loaded in the plotter is set to cut media.
12 Sheet lamp Green On The media loaded in the plotter is set to cut sheet.
Off The media loaded in the plotter is set to roll sheet.
13 Color lamp Red On The plot mode is set to color.
Off The plot mode is set to monochrome.
14 Black & white
lamp
Red On The plot mode is set to monochrome.
Off The plot mode is set to color.
15 High speed lamp Green On - The plot mode is set to High speed.
- When the Normal lamp is also on, the print mode is set to
High quality.
Off The plot mode is set to Normal.
16 Normal lamp Green On - The plot mode is set to Normal.
- When the Normal lamp is also on, the print mode is set to
High quality.
Off The plot mode is set to High speed.
17 LCD monitor - - This monitor displays the operation status and error
messages of the plotter.
No. Name Normal Setup menu display
