Xerox 7142 Service Manual

RJ-900C, RJ-901C Maintenance Manual Supplement Exploded View
5
Y Rail Assy
2006.04.19 Rev.A
X Rail Assy
Model Name : RJ-900C, RJ-901C
Exploded View
Cable guide (A1)
DE-22145
Media guide film B
DE-36749
Tube holder
DE-36539
Tapping screw M3 x 6 S tight cup
MS-5203006A
Flat clamp FCR35
E-FCR-35-V0
Tapping screw M4 x 8 S tight cup
MS-5204008A
Flanged hexagon nut M4 (serrated)
MS-9704000A
Flat washer (polished) M8
MS-8708000A
Y rail eccentric screw
DF-48585
Y rail mounting material R
DE-36528
Pressure locating
material R
DE-36553
Pressure locating material R
DE-36553
Roller guide
DE-36536 (A1)
DE-36544 (A0)
Clamp RMS-1V0
DF-48558
Photo interrupter SG2481
E-SG2481
CR origin sensor relay assembly
DF-48634
Lever sensor relay assembly
DF-48639
Tapping screw
M4 x 16 S tight cup
MS-5204016A
Pressure lever
DE-12558
Pressure lever
spring
DF-48587
Photo interrupter SG2481
E-SG2481
Y rail side plate R
DE-36525
Pressure bush 13
DF-47446
Pressure arm shaft
DE-36526 (A1)
DE-36527 (A0)
T fence
DE-36542(A1)
DE-22144 (A0)
Pressure arm
DE-22142
Pressure spring
DF-48582
Fence guide
DE-36540
Pressure roller shaft
DF-48584
Pressure roller
DF-48583
Pressure cam
DF-48581
Pressure bracket
DE-22141
Tapping screw M4 x 8
S tight cup
MS-5204008A
Tapping screw M4 x 8 S tight cup
MS-5204008A
Y rail mounting material L2
DF-48586
Pressure locating
material L
DE-36529
Y rail side plate L
DE-36538
Tapping screw M4 x 16
S tight cup
MS-5204016A
T fence spring
DF-48596
Stop rubber BA
TB-40010
CR motor
assembly
DE-36535
CR motor relay assembly
DE-48622 (A1)
DE-48623 (A0)
CR belt
DE-36534 (A1)
DE-36545 (A0)
Tapping screw M4 x 6
S tight cup
MS-5204006A
Tapping screw M4 x 6 S tight cup
MS-5204006A
CR motor mounting plate fixing material
DF-48591
Y rail mounting material L
DE-36530
Flanged hexagon nut
M4 (serrated)
MS-9704000A
Y rail eccentric screw
DF-48585
Y rail
DE-36533 (A1)
DE-36543 (A0)
Driven pulley shaft
DF-48592
Flat washer (polished) M8
MS-8708000A
Tapping screw M4 x 8 S tight cup
MS-5204008A
Pressure locating material R
DE-36529
CR driven pulley
DF-48593
Tension fixing spring
DE-36555
Driven pulley base
DE-36554
Tension adjusting plate
DF-48600
CR belt spring
DF-48595
Pan-head machine screw M4 x 30
MS-0104030A
Bearing holder
DF-48594
CR motor mounting plate
DE-36537
Bearing 684ZZ
DF-48917
CR motor assembly
DE-36535
Media guide film A
DE-36748
Fence guide assembly DF-49027
T fence A1_assembly DF-49024
T fence A0_assembly DF-49025
T fence spring
assembly
DF-49026
Pressure spring assembly
DF-49055
Pressure arm assembly DF-49052
Pressure roller shaft assembly DF-49054
Pressure roller assemblyޓ
DF-49053
CR belt A1ޓDF-49044
CR belt A0ޓDF-49045
CR driven pulley assemblyޓDF-49047
CR motor relay
assembly
DF-48991 (A1)
DF-48992 (A0)
CR_HP sensor, Lever sensor
DF-42240
Lever sensor relay assembly
DF-49004
CR origin sensor relay assembly
DF-49000
CR motor assembly
DF49021
