Xerox 7142 Service Manual

RJ-900C, RJ-901C Maintenance Manual Supplement Exploded View
4
X Rail Assy 2
Exploded View
2006.07.05 Rev.C
Cursor Assy
Model Name : RJ-900C, RJ-901C
Cursor
DE-12573
Bearing 684ZZ
DF-48917
Cursor shaft C BA
TB-40059
Height switching
cam
DE-36581
E type fixing ring
E-3
MS-8003000A
Height adjusting cam
DE-36570
Roller arm
DE-36568
Roller shaft_l
DF-48665
Cursor roller spring
DF-48671
Backing-plate
receiver spring
DF-48672
Backing-plate receiver
DE-22161
Blast adjusting piece
DE-36569
Head pressure
plate
DE-12575
Head pushing spring
DF-48674
Head holding piece
DE-36576
Print head ID 38V
DF-48651
Damper holder
DE-22163
Cutter holder
DE-12578
Cutter blade PE
DF-40735
Cutter cap
DE-36580
Cutter solenoid assembly (PE)
DE-34142
Lock kicker
DE-36579
Pan-head screw
with spring washer
and flat washer M3 x 8 Ni-3
MS-05030081
Pan-head screw
with spring washer
and flat washer
M3 x 8 Ni-3
MS-05030081
P tight cup M3 x 6 Ni-3
MS-59030061
P tight cup M3 x 6 Ni-3
MS-59030061
Hexagon
bearing
DF-48666
Cable cover L
DE-22165
Cable cover R
DE-12577
PG origin sensor relay
DF-48635
CR base
DE-12576
Clamp RMS-1VO
DF-48558
CR board cover
DE-22166
Edge saddle
(EDS-1208U)
E-EDS-1208U
Cursor roller shaft V
TB-49142
Hexagon
bearing
DF-48666
Cursor roller shaft V
TB-49142
CR_ENC
mounting plate
DF-48669
Pan-head screw
with spring washer
and flat washer (polished) M2 x 6 Ni-3
MS-05020061
CR encoder assembly
DF-48633
Bearing 684ZZ
DF-48917
Bearing 684ZZ
DF-48917
Pinch roller spacer BA
TB-40059
Height switching
cam DE-36581
Height adjusting cam
DE-36570
Height switching lever
DE-36571
Pan-head screw
with spring washer
and flat washer
M3 x 8 Ni-3
MS-05030081
Photo interrupter
SG2481
E-SG2481
Height switching shaft
DF-48667
Head unit pushing spring
DE-36582
Height switching flag
DF-48668
Height switching
lever spring
DF-48673
E type fixing ring E-3
MS-8003000A
P-EDGE
mounting plate
DE-36597
Damper assembly
DF-42110
Head pushing plate spring
DF-49141
Absorbent H
DF-49136
Head mounting
plate
DE-12574
Head adjusting cam
DE-36573
Slant adjusting
plate
DE-22162
Backing-plate
DE-36572
Head frame spring
DF-48675
Head tape wire
DF-48619
Tapping screw M3 x 6 S tight cup
MS-5203006A
Binding head
machine screw
M3 x 5 Ni-3bk
MS-1103005C
Head protective material
DE-36574
Head FG plate
DE-36575
Pan-head screw
with spring washer
and flat washer
M 3 x 6
MS-0503006A
P_EDGE sensor assembly
DE-36597
Pan-head screw
with spring washer
and flat washer
M 3 x 6
MS-0503006A
Pan-head screw
with spring washer
and flat washer M3 x 8 Ni-3
MS-05030081
Insulation film
DF-48682
CR board
assembly
DE-36548
Tapping screw
M3 x 8 S tight cup
MS-5203008A
Tapping screw
M3 x 8 S tight cup
MS-5203008A
Tapping screw
M3 x 8 S tight cup
MS-5203008A
P tight cup
M3 x 8 Ni-3
MS-59030081
Bearer fixing
material
DF-48670
3-way joint 3-2x2
DE-36577
Tube fixing material
DE-36578
Bearer mounting
material
DE-22164
Joint screw M7
DF-42127
Joint screw M7
DF-42127
O-ring joint M7
DF-42128
Joint screw M6
DF-42128
Cursor shaft C BA
TB-40003
Pan-head screw
with spring washer
and flat washer
M3 x 8 Ni-3
MS-05030081
To Damper assembly
DF-42110
Cutter solenoid spring BA
TB-40155
Pan-head screw
with spring washer
and flat washer
M3 x 8 Ni-3
MS-05030081
Tapping screw M3 x 8 S
tight cup
MS-5203008A
Pan-head screw
with spring washer
and flat washer M3 x 8 Ni-3
MS-05030081
Cutter spring PE
DF-40936
Cutter solenoid relay assembly
DE-48781
EMI set up plate
DF-49491
P_EDGE assembly
DF-48983
CR_ENC assembly
DF-48986
CR board
assembly
DF-48976
PG origin sensor relay assembly
DF-49001
Print head assembly
DF-49029
Head cable assembly
DF-49017
Damper assembly (BK)
DF-42229
Cutter solenoid assembly
DF-42234
Cutter spring
DF-44025
Solenoid relay assembly
DF-49003
Roller arm assembly
DF-49065
Carriage assembly
DF-49064
Head FG_assembly
DF-49018
Head tube A_assembly
DF-49036
Head tube B_assembly
DF-49037
Solenoid spring assembly
DF-49062
