Xerox Color C75 Press User Manual

Loading media in the Bypass tray
When using the Bypass tray (Tray 5):
• This tray is used primarily when using a small quantity and special media (such as
envelopes).
• Stock can be loaded either long or short edge feed (portrait or landscape).
• You must manually enter the paper size on the machine UI.
• If you use a non-standard paper size often, you can preset the paper size on the
device. The preset size then displays under Standard Sizes in the Tray 5 (Bypass)
screen. For information about setup, refer to the System Administration Guide.
• You can load up to 250 sheets of 20 lb/75 gsm paper.
• Do not load mixed-size paper into the Bypass tray (Tray 5).
• Do not load materials above the MAX line as indicated on the tray.
Loading paper in the Bypass tray (Tray 5)
1. Gently extend the Bypass tray (Tray 5) as necessary to accommodate the paper.
2. Hold the center of the paper guides and slide them to the desired paper size.
3. Select the appropriate paper stock for your print job.
4. Open the ream of paper with the seam side facing up.
5. Fan the sheets before loading them into the tray.
4-5Xerox
®
Color C75 Press
User Guide
Paper and other media

Xerox Color C75 Press Specifications

General

Copy speed (black, normal quality, A4)	75 cpm
Maximum print size	A3 (297 x 420 mm)
Media types supported	64 – 300 g/m2
Standard input capacity	1900 sheets
Maximum resolution	2400 x 2400 DPI
Standard printer languages	PCL 5c, PCL 5e, PCL XL, PDF 1.7+, PostScript 3
Standard interfaces	USB 2.0
Networking features	TCP/IP, Novell, NDS, IPX/SPX, IPP AppleTalk, IPP, NetBEUI, DHCP
Internal memory	- MB
Maximum duty cycle	300000 pages per month
Power requirements	100-240 VAC, 50/60 Hz
Dimensions (WxDxH)	1714 x 777 x 1372 mm
Type	Digital copier
