Parts List
Phaser 3435 5/08 5-13
PL 6 Frame (1 of 3)
No. Part No. Description QT’y Remark
5.6-0 - ELA HOU-FRAME 220V 1
5.6-0 - ELA HOU-FRAME 110V 1
5.6-1 - FRAME-M_BASE 1
5.6-2 - FRAME-M_EXIT 1
5.6-3 - ELA HOU-GUIDE DUP F 1 REP 16
5.6-3-1 - GUIDE-M_FRONT DUPLEX 1
5.6-3-2 - LEVER-ACTUATOR EMPTY 1
5.6-3-3 - PHOTO-INTERRUPTER 1
5.6-3-5 - SHEET-GUIDE FRONT DU 1
5.6-3-6 - CAM-CATCH 2
5.6-3-7 - PMO-BUSHING FEED 2
5.6-3-9 022N02292 MEA-ROLLER PICK UP 1 REP 15
5.6-3-9-1 - ROLLER-IDLE PICK UP 2
5.6-3-9-2 - HOUSING-M_PICK UP 1
5.6-3-9-3 - ROLLER-PICK UP 1
5.6-3-10 - SHAFT-PICK UP 1
5.6-3-11 - CAM-SHAFT PICK UP 1
5.6-3-12 - PMO-BUSHING_P/U,MP 1
5.6-3-13 022N02293 ROLLER-FEED 1
5.6-4 - SHAFT-FEED IDLE 1 REP 20
5.6-5 - BUSH-M-FEED IDLE 2
5.6-8 005N01031 MEA UNIT-CLUTCH 1 REP 20
5.6-8-1 - SHAFT-FEED 1
5.6-8-2 - PMO-HUB CLUTCH 1
5.6-8-3 - SPRING-TS 1
5.6-8-4 - PMO-COLLAR_SPRING 1
5.6-8-5 - GEAR-FEED 1 1
5.6-9 - MEA UNIT-BRACKET FEED 1 REP 20
5.6-9-1 - BRACKET-P-FEED 1
5.6-9-2 - GEAR-IDLE Z29 HELICAL 1
5.6-9-3 - RING-E 1
5.6-9-4 - GEAR-RETARD 39/19 1
5.6-9-5 - GEAR-T2 IDEL_Z27 1
5.6-9-6 - RING-E 2
5.6-10 - MEA UNIT-GEAR PICK UP 1
5.6-10-1 - GEAR-PICK UP_INNER 1
5.6-10-2 - GEAR-PICK UP_OUTER 1
5.6-10-3 - SPRING-CS 1
