Status Indicator RAPs
Phaser 3435 5/08 2-13
Figure 5
8. Pull the jammed paper out.
If the jammed paper does not move when you pull, push the pressure lever on each side up
to loose the paper, and then remove it.
Figure 6
1
9. Return the lever, door, stopper, and guide to their original position.
10.Close the rear cover. Printing automatically resumes.
In the Duplex Unit Area
If the duplex unit is not inserted correctly, paper jam may occur. Make sure that the duplex unit is
inserted correctly.
Duplex jam 0
1. Pull the duplex unit out of the printer.
To Next Page
