Status Indicator RAPs
Phaser 3435 5/08 2-7
RAP 4 Paper Jams
Clearing Paper Jams
Jams in the Paper Feed Area
In the Tray
1. Pull the tray 1
Figure 1
Message Location of Jam
Paper Jam 0 Open/Close Door In the paper feed area (tray 1, optional tray 2, multi-purpose tray)
Paper Jam 1 Around the print cartridge
Open/Close Door Paper Jam 2 Check Inside In the paper exit area
Duplex Jam 0 Check Inside In the duplex area
Duplex Jam 1 Open/Close Door Between the duplex unit and fuser area
To Next Page
