Xerox PHASER 3635 Service Manual

6-14
Phaser 3635MFP
GP 7
Draft 4
General Procedures and Information
GP 7 Machine Specifications
Specifications are correct at the time of publication. Machine specifications are subject to
change without notice. Refer to the following tables for machine specifications:
• Table 1 General Specifications.
• Table 2 Fax Specifications.
• Table 3 Scanner Specifications.
• Table 4 Copy Specifications.
• Table 5 Telephone Specifications.
• Table 6 Consumables.
• Table 7 Fuser Operating Temperatures.
• Table 8 HVPS Output.
Table 1 General specifications
Item Description
Configuration Desktop with 1 tray. Optional 2nd tray. Optional stand.
Operation System Windows 95/98/2000/NT4.0/Win-ME/XP/Longhorn/XP 64bit/
Citrix/Vista
MAC OS 8, 9, X 10.2, X 10.3 & Higher Unix/Linux
Duplex Printing Yes
Printing Speed 35ppm for 8.5x11, 33ppm for A4
Paper Tray Capacity 520 sheets (75 gsm)
Document Capacity (Input) DADF: 50 Sheets (50-120gsm)
Paper Capacity (Output) Output tray 250 sheets
Convenience Stapler Capacity 20 sheets (75 gsm)
External Interface Serial Interface: DADF, Tray 2
USB 2.0 device
USB 2.0 Host
Network
RJ45 for telephone
Option SOK slot
CPU 360 MHz
System Memory 256Mb
Warming up Time From power on: 85 Sec. From power save: 15 sec.
Absolute Storage Condition Temperature: -20C to 40C, Humidity: 10% RH to 90% RH
Operating Condition Temperature: 10C to 32C, Humidity: 20% RH to 80% RH
Recommended Operating Con-
dition
Temperature: 16C to 30C, Humidity: 30% RH to 70% RH
Dimension (W x D x H) Basic: 632 x 565 x 546mm (24.8 x 22.2 x 21.4 inches)
Weight Machine: 19.1Kg (42lb) (with CRU)
Tray 2: 7Kg (15.4lb)
Acoustic Noise Less than 54dB (Copy/Printing scanning mode)
Power Rating 110VAC-127VAC: 7A (max)
220VAC-240VAC: 4.5A (max)
Power Consumption (printing/
copying)
Avg. 750W
Power Consumption (power
save)
Avg. 35W
Power Consumption (standby) Avg. 100W
Power Consumption (peak) 1500W
LCD 800 by 480 line color TFT
Optional Memory 256Mb
Table 2 Fax specifications
Item Description
Communication Standard ITU G3, Super G3
Application Network Standard G3 PSTN (RJ-11), PABX
Data coding (Compression) MH/MR/MMR/JBIG/JPEG (Color/Transmission)
Modem speed 33600/31200/28800/26400/21600/14400/12000/ 9600/
7200/4800/2400bps
Transmission Speed Approximately 3 sec. (33,600 bps)
Effective Scanning Width 208 mm (8.2 inches)
Maximum Document Length
from DADF
356 mm (14 inches)
Grayscale 256 Levels
Paper Capacity (Input) DADF (Duplex Automatic Document Feeder): 50 Sheets
(75gsm)
FAX Mode Standard (203 x 98 dpi)
Fine (203 x 196 dpi)
Super Fine (Fine Photo) (300 x 300 dpi)
Super Fine (406 x 392 dpi)
Super Fine (600 x 600 dpi)
Halftone
Memory Fax stored on HDD (HDD= 80Gb)
Table 3 Scanner specifications
Item Description
Type Flatbed (with DADF)
Speed Color/Mono Gray: 0.73msec/line at 600 x 600 dpi
Mono Binary: 0.365msec/line at 300 x 300 dpi
Device Color CCD (Charge Coupled Device) Module
Interface IEEE1284 (ECP Support) USB (without HUB Mode)
Compatibility TWAIN Standard, WIA
Optical Resolution (H X V) 600 x 600 dpi
Halftone 256 Levels
Effective Scan width 208 mm (8.2 inches)
