Xerox PHASER 3635 Service Manual

3-1
Phaser 3635MFP
Image Quality
Draft 4
3 Image Quality RAPs
Image Quality RAPs
IQ1 Image Quality Entry RAP ......................................................................................... 3-3
IQ2 Blank Copies RAP.................................................................................................... 3-8
IQ3 Black Copies or Prints RAP...................................................................................... 3-9
IQ4 Blurred Image From the Scanner RAP..................................................................... 3-9
IQ5 Vertical Black Lines or Bands RAP .......................................................................... 3-10
IQ6 Vertical White Lines RAP ......................................................................................... 3-10
IQ7 Light Image RAP ...................................................................................................... 3-11
IQ8 Dark Image RAP ...................................................................................................... 3-12
IQ9 Background RAP...................................................................................................... 3-12
IQ10 Ghost Images RAP................................................................................................. 3-13
IQ11 Stains on Back of Paper RAP ................................................................................ 3-14
IQ12 Poor Fusing RAP.................................................................................................... 3-14
IQ13 Partial Blank Image (Not Periodic) RAP................................................................. 3-15
IQ14 Partial Blank Image (Periodic) RAP ....................................................................... 3-15
IQ15 Different Image Density (Left and Right) RAP........................................................ 3-16
IQ16 Horizontal Bands RAP............................................................................................ 3-16
IQ17 Periodic Printing Defects Check RAP .................................................................... 3-17
IQ18 DADF Lead Edge Offset RAP ................................................................................ 3-18
IQ19 Poor Registration RAP ........................................................................................... 3-18
Image Quality Specifications
IQS 1 Solid Area Density ................................................................................................ 3-19
IQS 2 Skew ..................................................................................................................... 3-20
IQS 3 Registration........................................................................................................... 3-20

Xerox PHASER 3635 Specifications

General

Print Technology	Laser
Print Speed	35 ppm
Print Resolution	Up to 1200 x 1200 dpi
Standard Paper Capacity	550 sheets
ADF Capacity	50 sheets
Duplex Printing	Yes
Scanner Type	Flatbed with ADF
Functions	Print, Copy, Scan, Fax
Processor	360 MHz
Connectivity	Ethernet
Maximum Paper Size	8.5 x 14 inches
Scanner Resolution	Up to 600 x 600 dpi
Network Connectivity	Ethernet
Display	7-inch color touchscreen
Weight	49 lbs
