Xerox® WorkCentre® 3215/3225 Multifunction Printer Service Manual
17-910 , 20-100
Status Indicator RAPs
17-910 Firmware Upgrade Fault
The firmware upgrade aborted due to an invalid file.
BSD-Reference: None
Initial Actions
1. Check the USB connection.
2. Verify that the correct firmware file is being used.
Procedure
Cycle the machine power and repeat upgrade procedure GP 7.
20-100 Fax Communication Error Fault
A communication error occurred during a fax transmission.
BSD-Reference: BSD 3.1B Printer Communication
Initial Actions
1. Call the target fax number to confirm a fax response.
2. Check condition of the fax line and connection.
3. Verify that the fax line is an analog phone line.
4. Switch Off the power then switch On the power.
5. Verify that the country setting is correct.
6. Resend the fax job.
7. Check fax communications to a different machine.
Procedure
Enter Diagnostic Mode. From the Control panel, select: [Report, Error Info, Print] to print the
Error Information Report. The target fax is causing the error.
YN
In Diagnostics, select: [Report, Fax Options] to verify Fax Send settings are at default.
Check that the Target Fax configuration is OK. The Target Fax is OK.
YN
Reconfigure Target Fax.
Reseat the Fax PWB. The fault clears.
YN
Replace the Fax PWB. PL 2.2.
Check the connection between the Fax board and the Main PWB. The connection is secure.
YN
Firmly reconnect the connector.
Replace the Main PWB (REP 1.8), PL 4.1.

Xerox WorkCentre 3225 Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Resolution	Up to 600 x 600 dpi
Monthly Duty Cycle	Up to 30, 000 pages
Paper Capacity	250 sheets
ADF Capacity	40 sheets
Memory	128 MB
First Page Out Time	As fast as 8.5 seconds
Processor	600 MHz
Paper Output Capacity	120 sheets
Duplex Printing	Manual
Copy Resolution	Up to 600 x 600 dpi
First Copy Out Time	As fast as 10 seconds
Maximum Number of Copies	99 copies
Scan Resolution	Up to 600 x 600 dpi
Fax Speed	33.6 Kbps
Weight	11.4 kg
Connectivity	USB 2.0, Ethernet
Media Sizes Supported	Letter, Legal, A4, A5, B5
Operating System Compatibility	Windows, Mac, Linux
Fax Transmission Speed	Approx. 3 seconds per page
