Xerox WorkCentre 3315DN User Manual

Loading Paper
Xerox WorkCentre 3315DN/3325DN/3325DNI
User Guide
18
Loading Paper
Paper Tray 1 and Paper Tray 2 (optional)
The paper level indicator on the front of trays 1 and 2 shows
the amount of paper currently left in the tray. When the tray
is empty, the indicator is completely lowered as shown in the
illustration: shows full, shows empty. Paper tray 1
can hold up to 250 sheets and paper tray 2 (optional) can
hold up to 520 sheets of 20 lb (80 g/m
2
) paper. For more
media specifications, refer to Media Specifications on
page 225.
To load the paper:
1. Pull out the paper tray and load paper into the tray, print
side down. Do not fill above the Maximum Fill line
indicated by the symbol .
2. Slide the paper length guide until it lightly touches the
end of the paper stack.
1 2
21
1
2


Xerox WorkCentre 3315DN Specifications

General

Brand	Xerox
Model	WorkCentre 3315DN
Category	All in One Printer
Language	English
