Xerox WorkCentre Pro 423 Service Manual

03/02 How to use the Diagnostic C/E Mode
WorkCentre Pro 423/428 2-149 CHAPTER 2 TROUBLESHOOTING
2.4.9.2 Input Check Chain Function Code List
Chain Function Part/Signal Ref. BSD
1 1 R/H INTERLOCK
1 2 FRONT INTERLOCK
1 10 CABINET INTERLOCK
5 60 DADF EMPTY SENSOR
5 61 DADF SIZE1 DOCUMENT SENSOR
5 62 DADF SIZE3 DOCUMENT SENSOR
5 63 DADF SIZE4 DOCUMENT SENSOR
5 64 DADF SIZE5 DOCUMENT SENSOR
5 65 DADF REGI SENSOR
5 66 DADF Paper Reverse Ejection Sensor
5 67 DADF PICK UP SENSOR
5 68 DADF Separation Encoder Sensor
5 69 DADF PRREGI1 SENSOR
5 70 DADF PRREGI2 SENSOR
5 71 DADF Paper Feed Section Cover Release Switch
6 6 DOCUMENT SIZE SENSOR (Slow Scan)
6 11 REGISTRATION SENSOR
6 21 PLATEN INTLOCK SWITCH
6 22 PLATEN ANGLE SWITCH
7 1 TRAY1 SIZE SENSOR
7 2 TRAY2 SIZE SENSOR
7 3 TRAY3 SIZE SENSOR
7 4 TRAY4 SIZE SENSOR
7 6 MSI SIZE SENSOR
7 7 TRAY1 NO PAPER SENSOR
7 8 TRAY2 NO PAPER SENSOR
7 9 TRAY3 NO PAPER SENSOR
7 10 TRAY4 NO PAPER SENSOR
7 12 MSI NO PAPER SENSOR
7 13 TRAY1 NEAR END SENSOR
7 14 TRAY2 NEAR END SENSOR
7 15 TRAY3 NEAR END SENSOR
7 16 TRAY4 NEAR END SENSOR
8 5 REGI SENSOR
8 6 T/A ROLL2 SENSOR
8 7 T/A ROLL3 SENSOR
8 31 DUP SENSOR
9 2 DRUM DETECT
94
TONE EMPTY
10 20 FUSER CONTROL SENSOR (Analog Value)
Chain Function Part/Signal Ref. BSD
10 23 FUSER EXIT SENSOR
12 1 FINISHER PAPER IN SENSOR
12 2 FINISHER REVERSE SENSOR
12 3 FINISHER TIMING SENSOR
12 4 FINISHER PAPER EXIT SENSOR
12 5 FINISHER TAMPER HOME POSITION SENSOR
12 6 FINISHER STACK HEIGHT SENSOR
12 7 FINISHER TOP COVER SENSOR
12 8 FINISHER PAPER PATH COVER SENSOR
12 9 FINISHER DOCKING SENSOR
12 10 STAPLER COVER SW
12 11 FINISHER PAUSE SW
12 12 FINISHER LEVER SENSOR
12 13 FINISHER UPPER LIMIT SENSOR
12 14 FINISHER NEAR FULL SENSOR
12 15 FINISHER FACE UP TRAY FULL SENSOR
12 16 STAPLE HEAD HOME POSITION SENSOR
12 17 STAPLE SELF PRIM SENSOR
12 18 LOW STAPLE SW
12 19 STAPLER CARTRIDGE SET SW
12 20 STAPLER UNIT LOCK SW
12 33 STAPLER UNIT HOME POSITION SENSOR
13 1 ALL SENSOR SWITCH CHECK (Analog Value)
(Excluding Key, Tray Size Sensor, and DADF
Sensor/Switch)
