Xinje VH6 Series User Manual

84
Group A2: Second motor parameters
Parameter
Name
Setting range
Default
value
Modify
Modbus
address
3: acceleration and deceleration time 3
4: acceleration and deceleration time 4
A2-38
Motor 2 torque boost
0.0%: Automatic torque boost
0.1%~30.0%
Model
setting
○
A226H
A2-40
Motor 2 oscillation
suppression gain
0~100
Model
setting
○
A228H
A2-41
Speed loop proportion gain 1
1~100
30
○
A229H
A2-42
Speed loop integral time 1
0.01s~10.00s
0.50
○
A22AH
A2-43
Speed loop proportion gain 2
1~100
20
○
A22BH
A2-44
Speed loop integral time 2
0.01s~10.00s
1.00
○
A22CH
A2-45
Switching frequency 1
0.00~A2-46
5.00
○
A22DH
A2-46
Switching frequency 2
P6-05~max output frequency (P0-13)
10.00
○
A22EH
A2-47
Speed loop integral property
Ones bit: integral separation
0: invalid
1: valid
0
○
A22FH
A2-48
Slip gain of vector control
50%~200%
100%
○
A230H
A2-49
SVC speed feedback filter
time
0.000s~1.000s
0.015
○
A231H
A2-51
Torque upper limit source
under speed control mode
0: Parameter setting (A2-52)
1: AI1
2: AI2
3: AI3
4: PULSE setting
5: communication setting
6: min(AI1,AI2)
7: max(AI1,AI2)
0
○
A233H
A2-52
Digital setting of torque
upper limit in speed control
mode
0.0%~200.0%
150.0%
○
A234H
A2-55
Proportional gain of
excitation regulation
0 ~ 60000
2000
○
A237H
A2-56
Integral gain of excitation
regulation
0 ~ 60000
1300
○
A238H
A2-57
Torque regulation
proportional gain
0 ~ 60000
2000
○
A239H
A2-58
Integral gain of torque
regulation
0 ~ 60000
1300
○
A23AH
