Xtreme TX90 6kVA - Unit Test, Calibration Setting Explanation

Xtreme Power Conversion Corporaon
TX90 6kVA & 10kVA Service Manual
Page 25
Uninterrupble Power Supply
Unit Test, Calibraon Seng Explanaon
VR Funcon Explanaon
PCB Number Funcon Locaon
MSDC0XX Adjust Charger Output Voltage VR1
CHEC0XX Adjust Charger Output Voltage VR1
Electrical Characteriscs
Baery Charging Voltage (25°C)
Model Baery Charging Voltage
TX90/T90 6kVA & 10kVA 273.0Vdc
Baery Low Warning and Baery Cut-o
Overload me out versus Inverter mode and Bypass mode
