TX90 6kVA & 10kVA Service Manual
Page 33
Uninterrupble Power Supply
The turns rao of Primary and secondary of the transformer is 1 to 1.
Input Coil: 0V~208V, Output Coil: 0V~120V
Calibraon2 Block: I/P Voltage → 208 system, O/P Voltage → 120V system
The turns rao Primary and Secondary of the transfomer is 208 to 120.
Frequency Converter (CVCF Mode) Seng Noce
The UPS can be set as Frequency Converter(CVCF mode). If the UPS is Dual Input Model, you have to make sure
the Bypass Input Breaker is set at “OFF” posion; on the contrary, if the UPS is Single Input Model, you have to
remove the power wire of the Bypass Input.
