7000 Series Parts Manual
12
Copyright © 2002-2020, ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved.
Reproduction in whole or in part without the express written permission of ASSA ABLOY Access and Egress
Hardware Group, Inc. is prohibited. Patent pending and/or patent www.assaabloydss.com/patents.
7170(F) Surface Vertical Rod
Item Part No. Description
1
Latch Assembly
6070100360048
7170, 7170F
(Must Specify Hand)
2
Cover
607110X003FIN 7170
Not Available 7170F
3 0300805047FIN
Sex Nut Pack (4)
(Fire Rated Only)
4 6015100281FIN
Rod Extension Assy., 24"
(-10 Device Only)
5 6015100278FIN
Rod Extension Assy., 12"
(-10 Device Only)
23 8195001549FIN
Screw Packet, Cover
#832 x 5/16"
UFPHMS (5)
32 607010X040FIN
Cover, Top & Bottom
Latches (2)
33
Top Latch
6070100049999 7170
6070100050999 7170F
34
8195001610000 SVR Pack
Consists of the following:
6071101005048 Top Mtg. Plate
6070101039048 Bottom Mtg. Plate
6070101067048 Top Rod Connector
9999994308999 Rod Connecting Pin
6015006150999 Drill Jig
6070101070018 Floor Bolt
6070101055200 Strike
8195001546000 Latch Mounting Screw Pack
8131110676048
Latch Mounting Screw (4)
(Wood Door Panic)
8195001576000 726 Top Strike Packet
Item Part No. Description
35
Bottom Bolt Case
6070100054000 7170
6070100053000 7170F
36 607010X052FIN Top Rod
37 6070100020FIN Bottom Rod Assembly
39
8195001514FIN Rod Guide Packet
Consists of the following:
6070109050999 Guide, Rod (1)
607010X051FIN Cover, Rod Guide (1)
8131100412058
Screw, #8 x 1/2 (2)
RPHMS (4)
8100110404FIN
Screw, #832 x 1/4" (2)
FPHMS (4)
42210_Yale_7000_PM.indd 1242210_Yale_7000_PM.indd 12 10/6/20 3:05 PM10/6/20 3:05 PM
