7000 Series Parts Manual
10
Copyright © 2002-2020, ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved.
Reproduction in whole or in part without the express written permission of ASSA ABLOY Access and Egress
Hardware Group, Inc. is prohibited. Patent pending and/or patent www.assaabloydss.com/patents.
7210M(F) Surface Vertical Rod
Item Part No. Description
1
Latch Assembly
6072100354048
7210M, 7210MF
(Must Specify Hand)
2
Cover
607010X069FIN 7210M
Not Available 7210MF
3 0300805047FIN
Sex Nut Pack (4)
Fire Rated Only
23 8195001549FIN
Screw Packet, Cover
#832 x 5/16"
UFPHMS (5)
32 607010X040FIN
Cover, Top & Bottom
Latches (2)
33
Top Latch
6070100049999 7210M
6070100050VEN 7210MF
34
8195001512000 SVR Pack
Consists of the following:
6071101038048 Top Mtg. Plate
6070101039048 Bottom Mtg. Plate
6070101067048 Top Rod Connector
9999994308999 Rod Connecting Pin
6015006150999 Drill Jig
6070101070018 Floor Bolt
6070101055200 Strike
8195001546000 Latch Mounting Screw Pack
0300805047FIN
Sex Nut Pack (4)
Fire Rated Only
8195001454200 791 Top Strike Packet
Item Part No. Description
35
Bottom Bolt Case
6070100054000 7210M
6070100053000 7210MF
36 607010X052FIN Top Rod
37 6070100020FIN Bottom Rod Assembly
39
8195001514FIN Rod Guide Packet
Consists of the following:
6070109050999 Guide, Rod (1)
607010X051FIN Cover, Rod Guide (1)
8131100412058
Screw, #8 x 1/2 (2)
RPHMS (4)
8100110404FIN
Screw, #832 x 1/4" (2)
FPHMS (4)
