Yale 7000 Series

7000 Series Parts Manual
44
Copyright © 2002-2020, ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved.
Reproduction in whole or in part without the express written permission of ASSA ABLOY Access and Egress
Hardware Group, Inc. is prohibited. Patent pending and/or patent www.assaabloydss.com/patents.
630F, 631F, 661F Trim
Item Part No. Description
1
Escutcheon Assembly
6070000710FIN 630F
6070000712FIN 631F
6070000716FIN 661F
3 See Chart Page 61 Cylinder, Mortise or Rim*
5 6020006206082 Housing, Cylinder, Rim
6 6070001235048 Screw, Cylinder Mtg. (2)
17
8195001405FIN Screw Packet, Mtg.
Consists of the following:
8100130670FIN Screw, 1/420 x 1OPHMS (3)
9999997156FIN Washer, #14 Finish (3)
38 600010-x639FIN Pull, Straight
*See page 61 for cylinder collar applications.
