Yale 7000 Series User Manual

7000 Series Parts Manual
48
Copyright © 2002-2020, ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved.
Reproduction in whole or in part without the express written permission of ASSA ABLOY Access and Egress
Hardware Group, Inc. is prohibited. Patent pending and/or patent www.assaabloydss.com/patents.
502F, 504F, 505F, 506F, 508F, 509F Trim
Item Part No. Description
1
Escutcheon Assembly
6072000128FIN 502F, 506F
6072000129FIN 504F, 505F, 508F, 509F
2 See Chart page 60 Lever/Knob
3 See Chart Page 61 Rim Cylinder
4 See Chart Page 61 Cylinder Collar
5
Housing & Cam Assembly
6072000159000 502F, 506FHousing,Cyl.
6072006145082 504F, 505F, 508F, 509F
6 6070001235048 Screw, Cylinder Mounting (2)
7 8100162200999 Screw, NL Function
16 6070009001999 Thimble Insert, Nylon Not Shown
19 6070001306999 Spring Under Tailpiece Not Shown
25 6072001120059 Plate, Cover
26 9999995702999 Spring, Extension (Levers Only)
27 6072001125059 Nut, Spring Post (Levers Only)
28
Rack & Tailpiece Assy.
6072000164000 Levers/Knobs
29 6072001147059 Lever, Clutch
30 6072001083059 Pin, Clutch Lever
31 9999994617999 Retainer, Clutch Lever Pin (2)
32 9999993508036 Nut, Cover Plate (2) Not Shown
33 6072001142000 Hub Not Shown
34 9999990246999 Bushing, Nylon Not Shown
35 6072001104059 Washer, Grip Not Shown
36 8106110410036 Screw, 832 x 7/16, Spindle Not Shown
37
Spring, Rack (2)
6072001134000 Lever
6072001133000 Knob, Thumbturn
