500F, 501F, 503F, 507F Trim
Item Part No. Description
1
Escutcheon Assembly
6072000151FIN 500F
6072000123FIN 501F
6072000127FIN 503F
6072000126FIN 507F
2 6072000156FIN Thumbturn / Spindle Assembly
3 See Chart Page 61 Cylinder, Rim
4 See Chart Page 61 Collar, Cylinder
5
Housing & Cam Assembly
6072000159000 503F, 507F
6020006206082 501F, Housing, Cylinder
6 6070001235048 Screw, Cylinder Mounting (2)
7 8100162200999 Screw, NL Function
16 6070009001999 Thimble Insert, Nylon Not Shown
19 6070001306999 Spring Under Tailpiece for 503F, 507F Not Shown
25 6072001120059 Plate, Cover
28 6072000164000 Rack & Tailpiece Assembly
29 6072001147059 Lever, Clutch (503F)
30 6072001083059 Pin, Clutch Lever (503F)
31 9999994617999 Retainer, Clutch Lever Pin (2) (503F)
32 9999993508036 Nut, Cover Plate (2)
33 6072001142000 Hub Not Shown
34 9999990246999 Bushing, Nylon Not Shown
35 6072001104059 Washer, Grip Not Shown
36 8106110410036 Screw, 832 x 7/16 Spindle Not Shown
37 6072001133000 Spring, Rack (2)
42210_Yale_7000_PM.indd 5042210_Yale_7000_PM.indd 50 10/6/20 3:05 PM10/6/20 3:05 PM
