Yale 7000 Series User Manual

7000 Series Parts Manual
54
Copyright © 2002-2020, ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved.
Reproduction in whole or in part without the express written permission of ASSA ABLOY Access and Egress
Hardware Group, Inc. is prohibited. Patent pending and/or patent www.assaabloydss.com/patents.
513F, 517F Trim
Item Part No. Description
1
Escutcheon Assembly
6072000154FIN 513F Top
6072000155FIN 517F Top
6072000120FIN Bottom
2 6072000156FIN Thumbturn/Spindle Assy.
3 See Chart Page 61 Cylinder, Rim
4 See Chart Page 61 Collar, Cylinder
5
Housing , Cylinder
6072000159000 513F
6072006145082 517F
6 6070001235048 Screw, Cylinder Mounting (2)
7 8100162200999 Screw, NL Function
16 6070009001999 Thimble Insert, Nylon Not Shown
17
8195001476FIN Screw Packet, Mtg.
Consists of the following:
8100130670FIN Screw, 1/420 x 1 OPHMS (1)
9999997156FIN Washer, #14 Finish (1)
19 6070001306999 Spring Under Tailpiece 513F Not Shown
25 6072001120059 Plate, Cover
28 6072000164000 Rack & Tailpiece Assy
29 6072001147059 Lever, Clutch (513F)
30 6072001083059 Pin, Clutch Lever (513F)
31 9999994617999 Retainer, Clutch Lever Pin (2) (513F)
32 9999993508036 Nut, Cover Plate (2)
33 6072001142000 Hub (Not Shown)
34 9999990246999 Bushing, Nylon Not Shown
35 6072001104059 Washer, Grip Not Shown
37 6072001133000 Spring, Rack (2) Not Shown
38 607200X136FIN Pull, Offset
39 6070001039048 Screw Post (2)
40 9999997154036 Lockwasher, Screw Post (2)
50 9999580044999 Pin, 5/32 x 11/8, Groove Not Shown
