7000 Series Parts Manual
58
Copyright © 2002-2020, ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved.
Reproduction in whole or in part without the express written permission of ASSA ABLOY Access and Egress
Hardware Group, Inc. is prohibited. Patent pending and/or patent www.assaabloydss.com/patents.
541F, 546F, 548F, 549F Trim
Item Part No. Description
1 1454012711FIN Rose Scalp
2
Lever
Plain
1454016640FIN AU - Augusta
1454036650FIN MO - Monroe
1454016062FIN PB - Pacific Beach
Cylinder
1454076038FIN AU - Augusta
1454076042FIN MO - Monroe
1454076062FIN PB - Pacific Beach
Yale I/C (6 Pin)
1454076021FIN AU - Augusta
1454076045FIN MO - Monroe
1454076065FIN PB - Pacific Beach
Yale I/C (7 Pin)
1454076022FIN AU - Augusta
1454076042FIN MO - Monroe
1454076066FIN PB - Pacific Beach
Best, Arrow, Falcon SFIC (6 & 7 Pin)
1454076056FIN AU - Augusta
1454076048FIN MO - Monroe
1454076068FIN PB - Pacific Beach
7 1454071102000 Tool, Lever Removal Not Shown
11 107S Schlage
®
Retrofit Kit
15 See Chart Page 61 Cylinder
16 1454079201999 Spacer, Cylinder
