7000 Series Parts Manual
18
Copyright © 2002-2020, ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved.
Reproduction in whole or in part without the express written permission of ASSA ABLOY Access and Egress
Hardware Group, Inc. is prohibited. Patent pending and/or patent www.assaabloydss.com/patents.
7220M(F) Concealed Vertical Rod
Item Part No. Description
1
Latch Assembly
6072200354048
7220M, 7220MF
(Must Specify Hand)
2
Cover, Latch Assembly
607000X353FIN
7220M
Not Available 7220MF
35
Bottom Bolt Case
6070200058048 7220M
6070200055048 7220MF
36 6072201019059 Top Rod
46
8195001456000 CVR Pack
Consists of the following:
6070101070018 Floor Bolt
6070101055200 Strike
8195001454200 791 Top Strike Packet
6071201047048 Pin, Rod Yoke (2)
6071401026059 Set Screw, Yoke Pin
9999580045999 Cotter Pin (5)
9999994526999 Ring, Retaining (2)
8195001548058 Screw Pack
8100140430036 2" Temp Screw (2)
47
Top Latch & Bracket Assembly
6070200057000 7220M
6070200060000 7220MF
49 6070200059000
Bottom Rod & Coupler
Assembly
51 6072207025000 Top Rod Tube
52 6072200030999 Arm & Bracket Assy (2)
