623F, 627F Trim
Item Part No. Description
1 6070000705FIN Escutcheon Assy. 623F, 627F
2 See Chart page 60 Lever / Knob
3 See Chart page 61 Cylinder, Rim*
5 6020006206082 Housing, Cylinder
6 6070001235048 Screw, Cylinder Mounting (2)
11 6070001328048 Gear, Drive
12 6070006220999 Universal Spring Hub, Lever
14 9999580047999 Cotter Pin
15 9999993516999 Nut, Spindle
16
6070009001999 Thimble Insert, Nylon
(Levers) Not Shown
17
8195001476FIN Screw Packet, Mtg.
Consists of the following:
8100130670FIN Screw, 1/420 x 1
OPHMS (2)
9999997156FIN Washer, #14 Finish (2)
18
Spring, Grip Return
6070001234999 Knob Not Shown
6070001220999 Levers, Universal Spring
*See page 61 for cylinder collar applications.
