652F, 654F, 656F, 658F Trim
Item Part No. Description
1
Escutcheon Assembly
6070000703FIN Cylinder x Lever (656F) or Knob (652F)
6070000702FIN Blank x Lever (658F) or Knob (654F)
2 See Chart page 60 Lever
3 See Chart Page 61 Cylinder, Mortise*
14 9999580047999 Cotter Pin
15 9999993518999 Nut, Spindle
16 6070009001999
Thimble Insert, Nylon
(Levers) Not Shown
17
8195001476FIN Screw Packet, Mtg.
Consists of the following:
8100130670FIN
Screw, 1/420 x 1
OPHMS (2)
9999997156FIN Washer, #14 Finish (2)
23 6099580047999 Washer, Spindle
24 6070001328048 Gear
25
Spindle
6070301045048 13/4" - 21/4"
6070301026048 21/4" - 3"
* See page 61 for cylinder collar applications
