Yale 7000 Series User Manual

7000 Series Parts Manual
62
Copyright © 2002-2020, ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved.
Reproduction in whole or in part without the express written permission of ASSA ABLOY Access and Egress
Hardware Group, Inc. is prohibited. Patent pending and/or patent www.assaabloydss.com/patents.
Strikes
Rim Devices
Vertical Rod Devices
Mortise Devices
11/16"
(17mm)
3-1/2"
(89mm)
1-1/4"
(32mm)
1"
(25mm)
3-1/2"
(89mm)
1-1/4"
(32mm)
2"
(51mm)
3"
(76mm)
1/2"
(13mm)
757F
Standard
7100(F), 7150(F), 7200M(F), 7250M(F)
793
Optional
7100, 7150, 7200M, 7250M
759
Standard
7200 Rim
1-3/4"
(44mm)
2"
(50mm)
1-1/8"
(41mm)
1"
(25mm)
2-5/8"
(67mm)
791
Standard
7110, 7120 Top
797
Bracket for SVR Top Strike
in Flush Transom Opening
761
Standard
7160 Top
726
Standard
7170 Top
2-7/32"
(64mm)
9/16"
(14mm)
1-1/16"
(27mm)
2-5/8"
(67mm)
1/2"
(25mm)
1-1/16"
(27mm)
702
Floor Strike for Bottom
Pullman Latch Option
790
Standard
All Vertical Rod Devices
794
Floor Strike for fire openings using saddle threshold, or flush floor mount
4-7/8"
(124mm)
1-1/4"
(32mm)
3-1/2"
(89mm)
4-7/8"
(124mm)
1-1/4"
(32mm)
798
Standard
All Mortise (Non-Handed)
202
Standard Box
for ANSI Prep
718
Open Back Strike
for Door Pair When Code Allows Use
