632F, 634F, 662F Trim
Item Part No. Description
1
Escutcheon Assembly
6070000713FIN 632F
6070000711FIN 634F
6070000717FIN 662F
3 See Chart Page 61 Cylinder, Mortise or Rim*
5 6020006206082 Housing, Cylinder
6 6070001235048 Screw, Cylinder Mtg. (2)
17
8195001467FIN Screw Packet, Mtg.
Consists of the following:
6070001039048 Threaded Post (1)
8100110674036 1/420 x5/8” (1) RHPMS
8100130670FIN 1/420 x1” (3) OHPMS
9999997156FIN Washer #14 Finish (3)
38 600010X639FIN Pull, Straight
*See page 61 for cylinder collar applications.
