Yale 7000 Series User Manual

7000 Series Parts Manual
16
Copyright © 2002-2020, ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved.
Reproduction in whole or in part without the express written permission of ASSA ABLOY Access and Egress
Hardware Group, Inc. is prohibited. Patent pending and/or patent www.assaabloydss.com/patents.
7120(F)/7220 Concealed Vertical Rod
Item Part No. Description
1
Latch Case Assembly
6070200360048
7120, 7120F
Must Specify Hand)
6072200354048
7220
(Must Specify Hand)
2
Cover, Latch Assembly
607100X025FIN
7120
Not Available 7120F
607000X353FIN 7220
35
Bottom Bolt Case
6070200058048 7120
6070200055048 7120F
6072200065048 7220
36 6072201019059 Top Rod
46
8195001456000 CVR Pack for 7120 & 7220
Consists of the following:
6070101070018 Floor Bolt
6070101055200 Strike
8195001454200 791 Top Strike Packet
6071201047048 Pin, Rod Yoke (2)
6071401026059 Set Screw, Yoke Pin
9999580045999 Cotter Pin (5)
9999994526999 Ring, Retaining (2)
8100140430036 2" Temp Screw (2)
8195001548058 Screw Pack
47
Top Latch & Bracket Assembly
6070200057000 7120
6070200060000 7120F
6072200066048 7220
49 6070200059000 Bottom Rod & Coupler Assembly
51 6072207025000 Top Rod Tube
52 6072200030999 Arm & Bracket Assy (2)
