7000 Series Parts Manual
8
Copyright © 2002-2020, ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved.
Reproduction in whole or in part without the express written permission of ASSA ABLOY Access and Egress
Hardware Group, Inc. is prohibited. Patent pending and/or patent www.assaabloydss.com/patents.
7110(F)/7210 Surface Vertical Rod
Item Part No. Description
1
Latch Assembly
6070100360048
7110, 7110F
(Must Specify Hand)
6072100354048
7210
(Must Specify Hand)
2
Cover
607110X003FIN 7110
(Not Available) 7110F
607010X069FIN 7210
3 0300805047FIN
Sex Nut Pack (4)
Fire Rated Only (2 Packs)
23 8195001549FIN
Screw Packet, Cover
#832 x 5/16"
UFPHMS (5)
32 607010X040FIN
Cover, Top & Bottom
Latches (2)
33
Top Latch
6070100049999 7110, 7210
6070100050999 7110F
Item Part No. Description
34
8195001512000 SVR Pack
Consists of the following:
6070101038048 Top Mtg. Plate
6070101039048 Bottom Mtg. Plate
6070101067048 Top Rod Connector
9999994308999 Rod Connecting Pin
6015006150999 Drill Jig
6070101070018 Floor Bolt
6070101055200 Strike
8195001546000 Latch Mounting Screw Packet
8195001454200 791 Top Strike Packet
35
Bottom Bolt Case
6070100054000 7110, 7210
6070100053000 7110F
36 607010X052FIN Top Rod
37 6070100020FIN Bottom Rod Assembly
39
8195001514FIN Rod Guide Packet
Consists of the following:
6070109050999 Guide, Rod (1)
607010X051FIN Cover, Rod Guide (1)
8131100412058
Screw, #8 x 1/2 (2)
RPHMS (4)
8100110404FIN
Screw, #832 x 1/4" (2)
FPHMS (4)
40 8195001464200
Blade Stop Block Packet (7210
only)
