7000 Series Parts Manual
14
Copyright © 2002-2020, ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved.
Reproduction in whole or in part without the express written permission of ASSA ABLOY Access and Egress
Hardware Group, Inc. is prohibited. Patent pending and/or patent www.assaabloydss.com/patents.
7170(F) LBR Surface Vertical Rod
(Less Bottom Rod)
Item Part No. Description
1
Latch Assembly
6070100360048
7170, 7170F
(Must Specify Hand)
2
Cover
607110X003FIN 7170
Not Available 7170F
3 0300805047FIN Sex Nut Pack (4), Fire Only
4 6015100281FIN
Rod Extension Assy., 24"
(-10 Device Only)
5 6015100278FIN
Rod Extension Assy., 12"
(-10 Device Only)
23 8195001549FIN
Screw Packet, Cover
#832 x 5/16"
UFPHMS (5)
32 607010X040FIN Cover, Top & Latch
33 6070100050999 Top Latch, 7170(F)
Item Part No. Description
34
8195001562000 SVR Pack
Consists of the following:
6071101005048 Top Mtg. Plate
6070101067048 Top Rod Connector
9999994308999 Rod Connecting Pin
6015006150999 Drill Jig
8195001613000
Latch Mounting Screw
Pack
8131110676048
Latch Mounting Screw(2)
(wood doors, panic)
8195001576000 726 Top Strike Packet
36 607010X052FIN Top Rod
39
8195001514FIN Rod Guide Packet
Consists of the following:
6070109050999 Guide, Rod (1)
607010X051FIN Cover, Rod Guide (1)
8131100412058
Screw, #8 x 1/2 (2)
RPHMS (4)
8100110404FIN
Screw, #832 x 1/4" (2)
FPHMS (4)
55 6071100002999
Popper Packet
[Fire Rated (F) Only]
42210_Yale_7000_PM.indd 1442210_Yale_7000_PM.indd 14 10/6/20 3:05 PM10/6/20 3:05 PM
