Yale 7000 Series User Manual

7000 Series Parts Manual
28
Copyright © 2002-2020, ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved.
Reproduction in whole or in part without the express written permission of ASSA ABLOY Access and Egress
Hardware Group, Inc. is prohibited. Patent pending and/or patent www.assaabloydss.com/patents.
Touchbar
*Covers which bare the UL Listing mark for Fire-Rating cannot be shipped with that marking. Therefore, covers for Fire-Rated Latch Case
Assemblies are not available.
Item Part No. Description
1
Latch Case Assembly
(Reversible) Specify Hand
6070000419048 7100
6070000425048 7100F
6072000354048 7200, 7200M
6072000362048 7200MF
6071500005048 7150, 7150F
6072500001048 7250, 7250M(F)
6070100360048 7110(F), 7170(F)
6072100354048 7210, 7210M(F)
6070200360048 7120(F), 7160(F)
6072200354048 7220, 7220M(F)
6070300382048 7130(F) (Includes Trim Slide)
2
*Cover, Latch Assembly
607100X026FIN 7100
607000X111FIN 7200, 7200M
607150X001FIN 7150
607250X001FIN 7250, 7250M
607110X003FIN 7110, 7170
607010X069FIN 7210, 7210M
607100X025FIN 7120, 7160, 7130
607000X353FIN 7220, 7220M
3
Bottom Rail
607000X079FIN 36" 7100 Series
607200X058FIN 36" 7200 Series
607200X066FIN 48" 7100/7200 Series
5
Bar & Carrier Assembly
6070000423000 36" 7100 Series
6072000356000 36" 7200 Series
6070000424000 48" 7100/7200 Series
6
Cover, Bar
607000X083FIN 36"
607000X084FIN 48"
7
Cover, End
607000X359FIN 36" std. 7100 Series
607000X362FIN 36" 7100 Series Cylinder Dogging
607200X360FIN 36" std. 7200 Series
607200X363FIN 36" 7200 Series Cylinder Dogging
607200X361FIN All 48" std.
607200X364FIN All 48" Cylinder Dogging
8 6070006115999 Touch Pad Cap, Front
9 6070006120999 Touch Pad Cap, Rear
10 6070009088999 Bar Cap, Black Nylon
Item Part No. Description
11 607000X360FIN End Cap
12 6072009216999 Trim Slide (All except Mortise)
13 6070001320048 Trim Slide Retainer
14
Dogging Assembly
6070000406048 Standard Hex Key Dog.
6070000801999 Cylinder, Dogging
15 6070001131036 Dogging Key (5/32" hex)
16 9999994123999 Dogging Hole Plug
17 6070002421000 Cylinder Nut
18 6020009153999 Cylinder Spacer Sleeve
19
Collar, Dogging Cylinder
None Required 11/8" Cylinder
101765X001FIN 11/4" Cylinder
101765X013FIN 11/2" Cylinder
20 As Ordered Dogging Cylinder (Mortise)
21
8195000605FIN End Clamp Packet
Consists of the following:
6070001423048 End Clamp (4 Wood Screws)
6070001349048 Mounting Screws (4)
6070001131036
Hex Dogging Key
(Except Fire Rated)
8195001549FIN Cover Screw Packet (6)
22 6070001391999
Screw, Touch Bar Caps, Torx Cap
#632 x 3/4" (4)
23 8195001549FIN
Screw Packet, Cover
#832 x 5/16" FHUMPH (5)
24 8144140514048
Screw, Hex Dogging Assy,
#1024 x 5/8" PHTTPN (2)
25 8137110412048
Screw, Trim Slide,
#832 x 1/2" FHTPH
26 8140140404048
Screw, Latch Head to Carrier,
#832 x 1/4" PHTCPH (2)
28 0300805047FIN
Sex Nut Packet (4)
Fire-rated Devices incl.
54 8142140508036
Screw, #1024 x 3/8 Type F
THP (4)
56 8195000620FIN Flush End Cap Kit
57 8140110558048
Screw, Cylinder Dogging Assy,
#1032 x 3/8 FHPH
42210_Yale_7000_PM.indd 2842210_Yale_7000_PM.indd 28 10/6/20 3:05 PM10/6/20 3:05 PM
