Mullions
2
3
2
4
1
3
Item Part No. Description
1 6072000011FIN Mullion 8’ M300
2
Top Retainer Packs:
6070000759 M200(F)
6070000755 KRM200(F)
3
Bottom Retainer Packs:
6070000763 M200(F)
6070000760 KRM200(F)
4 6070000750
Locking Mechanism,
KRM200(F)
5 See Chart Page 61 Cylinder, Mortise
7
8195001417078 Stabilizer Kit (optional)
contains:
Bracket, Stabilizer (2)
Stabilizer (2)
Spacer, Stabilizer (4)
Screw, #1024 x 3/4"
FHMPH (4)
Screw, #1024 x 1" FHMPH (4)
8
8195001416FIN Mounting Bracket Packet
contains:
Mullion Mounting Plate (2)
Screw, 1/420 x 1/2
FHUMPH (6)
Anchor, 1/420 Masonry (3)
9
8195001414FIN Carriage Bolt Packet
contains:
Bolt, 1/420 x 13/4" Carriage
Not Shown 8195001523FIN
Parts Packet contains: Items 7,
8 and 9
M200(F) KRM200(F)
9
7
1
9
9
8
8
M300
