620F, 621F, 651F Trim
Item Part No. Description
1
Escutcheon Assembly
6070000648FIN 620F
6070000614FIN 621F
6070300193FIN 651F
3 See Chart Page 61 Cylinder, Rim or Mortise*
5 6020006206082 Housing, Cylinder 621F
6 6070001235048 Screw, Cylinder 621F Mounting (2)
17
8195001476FIN Screw Packet, Mtg.
Consists of the following:
8100130670FIN
Screw, 1/420 x 1
OPHMS (2)
9999997156FIN Washer, #14 Finish (2)
* See page 61 for cylinder collar applications.
