Yale 7000 Series User Manual

7000 Series Parts Manual
40
Copyright © 2002-2020, ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved.
Reproduction in whole or in part without the express written permission of ASSA ABLOY Access and Egress
Hardware Group, Inc. is prohibited. Patent pending and/or patent www.assaabloydss.com/patents.
673F, 675F Trim
Item Part No. Description
1
Escutcheon Assembly
6070000718FIN 673F
6070000717FIN 675F
2 601530X114FIN Thumbpiece
3 See Chart Page 61 Cylinder, Mortise* 673F
17
Screw Packet, Mtg.
8195001405FIN 13/4" - 2" Doors
8195001453FIN 21/4" Doors
38 600010X639FIN Pull, Straight
39 6070001039048 Screw Post
40 9999997154036 Lock Washer, Screw Post (2)
41 6015301133999 Spring, Thumbpiece
44 8100110674036 Screw, 1/420 x 11/4 FHPMS
45 6070001460048
Thumbpiece, Trim Spacer
(Not Shown)
46 6015001806059 Bracket, Thumbpiece
48 6015007244000 Pin, Thumbpiece
49 9999994517999 Tru-Arc Ring
*See page 61 for cylinder collar applications.
