633F, 635F Trim
Item Part No. Description
1
Escutcheon Assembly
6070000715FIN 633F
6070000714FIN 635F
2 607000X192FIN Thumbpiece
3 See Chart Page 61 Cylinder, Rim* (633F)
5 6070000215000 Housing & Cam Assembly
6 6070001235048 Screw, Cylinder Mounting (2)
7 8100162200999 Screw, NL Function
9 8144140308036 Screw, Tailpiece Plate, #6 x 3/8 PHTTPH (2)
10 6070000611059 Tailpiece Assembly
17
8195001476FIN Screw Packet, Mtg.
Consists of the following:
8100130670FIN Screw, 1/420 x 1OPHMS (3)
9999997156FIN Washer, #14 Finish (3)
19 6070001306999 Spring Under Tailpiece
20 6070001305059 Hex Nut/Bushing for Spring
38 6000102639FIN Pull, Straight
39 6070001039048 Screw Post
40 9999997154036 Lock Washer, Screw Post
41 9999995697999 Spring, Thumbpiece (2)
42 6070001190059 Slider, Thumbpiece
43 6070000214000 Housing, Tailpiece Assy.
48 6070001045059 Pin, Thumbpiece
49 6070001189059 Thumbpiece Support Bracket
* See page 61 for cylinder collar applications.
