7000 Series Parts Manual
22
Copyright © 2002-2020, ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved.
Reproduction in whole or in part without the express written permission of ASSA ABLOY Access and Egress
Hardware Group, Inc. is prohibited. Patent pending and/or patent www.assaabloydss.com/patents.
7160(F) LBR Concealed Vertical Rod
(Less Bottom Rod)
Item Part No. Description
1
Latch Case Assembly
6070200360048 7160, 7160F (Specify Hand)
2
Cover, Latch Assembly
607100X025FIN 7160
Not Available 7160F
36 6072201019059 Top Rod
37
Rod Extension Assembly
6015100282000 12" Rod Assembly
6015100281000 24" Rod Assembly
46
8195001605000 CVR Pack
Consists of the following:
6071601004999 761 Top Strike Packet
6071201047048 Pin, Rod Yoke (1)
6071401026059 Set Screw, Yoke Pin
6070201064059 Yoke Pin Spacer (1)
9999580045999 Cotter Pin (3)
9999994526999 Ring, Retaining (1)
8100110512058 Screw, 1024 x 1/2 FHMPH (6)
8100140430036 8x32x2 Temp Screw (1)
47 6071600060000 Top Latch & Bracket Assembly, 7160(F)
51 6072207025000 Top Rod Tube
52 6072200030000 Arm & Bracket Assembly (1)
55 6071100002999 Popper Pack (Fire Rated Only)
