Yale 7000 Series

7000 Series Parts Manual
30
Copyright © 2002-2020, ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved.
Reproduction in whole or in part without the express written permission of ASSA ABLOY Access and Egress
Hardware Group, Inc. is prohibited. Patent pending and/or patent www.assaabloydss.com/patents.
603F, 622F, 624F, 625F, 626F, 628F, 629F Trim
Item Part No. Description
1
Escutcheon Assembly
6070000612FIN 603F, 622F, 624F, 625F, 626F
6070000615FIN 628F, 629F
2 See Chart page 60
Lever/Knob/Thumbturn Assy.
(603F)
3 See Chart page 61 Cylinder, Rim*
5 6070000215000 Housing & Cam Assy.
6 6070001235048
Screw, Cylinder
Mounting (2)
7 8100162200999 Screw, NL
8 6070009002999 Driver Gear Assembly
9 8144140308036
Screw, Tailpiece Plate, #6 x 3/8",
PHTTPH (2)
10
Tailpiece Assembly
6070000611059
13/4" Door
Without Shim Kit
6070000217059
2" - 21/4" Door or Std. Door with
Shim Kit
11
Gear, Drive
6070001328048
Thumbturn/Lever (603F,
626F, 628F)
6070001011059 Knob/Rigid Lever (629F, 625)
6070001339048 Knob Gear (622F, 624F)
*See page 61 for cylinder collar applications.
Item Part No. Description
12 6070006220999 Universal Spring Hub, Lever
14 9999580047999 Cotter Pin
15 9999993516999 Nut, Spindle
16 6070009001999
Thimble Insert, Nylon
(Levers) Not Shown
17
8195001476FIN Screw Packet, Mtg.
Consists of the following:
8100130670FIN
Screw, 1/420 x 1
OPHMS (2)
9999997156FIN Washer, #14 Finish (2)
18
Spring, Grip Return
6070001234999 Knob Not Shown
6070001220999 Levers, Universal Spring
19 6070001306999
Spring Not Shown Under
Tailpiece
20 6070001365999
Hex Nut / Bushing for
Spring Not Shown
21 6070001236059
Washer Under
Tailpiece (2) Not Shown
