Yamaha EF7000 - Replacing the Engine Oil

2-6
CHK
ADJ
PERIODIC MAINTENANCE
REPLACING THE ENGINE OIL
1. Warm up the engine for several minutes,
and then stop the engine.
2. Remove:
9 Oil filler cap 1
9 Oil drain bolt 2
9 Oil drain bolt gasket 3
3. Drain:
9 Engine oil
Place the oil pan under the engine and
drain the engine oil.
4. Install:
9 Oil drain bolt gasket 3
9 Oil drain bolt 2
27 Nm (2.7 m · kgf, 20 ft · lbf)
5. Fill:
9 Engine oil
Make sure to fill with the recommended
engine oil from the oil filler hole in the
crankcase.
Recommended engine oil:
A
YAMALUBE 4 (10W-40),
SAE 10W-30 or 10W-40
B
SAE #30
C
SAE #20
D
SAE 10W
Recommended engine oil grade:
API Service SE type or higher
Engine oil quantity:
1.1 L (1.16 US qt, 0.97 Imp qt)
6. Check:
9 Engine oil level
(Refer to “ENGINE OIL LEVEL” on 2-5)
7. Install:
9 Oil filler cap
1
2
3
0°C
å
YAMALUBE 4 (10W-40)
∂
SAE 10W
ç
SAE #20
∫
SAE #30
32°F
25°C
80°F
