Yamaha EF7000 - AIR FILTER

3-6
ENG
AIR FILTER
4
6
1
2
3
11 Nm (1.1 m á kgf, 8.0 ft á lbf)
5
7
10 Nm (1.0 m á kgf, 7.2 ft á lbf)
1.6 Nm (0.16 m á kgf, 1.2 ft á lbf)
Order Job/Parts to remove Q’ty Remarks
Removing the air filter Remove the parts in the order listed.
1 Air filter cover 1
2 Air filter element 1
3 Element fitting plate 1
4 Plate 1
5 Air filter case 1
6 Breather hose 1
7 Gasket 1
AIR FILTER
